Philips B4X89A
- Date: 1958, but available until 1960. This model was built in 1958
- Wooden cabinet with polystyrene front panel.
- Bands: SW1: 17-50m, SW2: 60-180m, MW: 200-550, LW: 750-2000m.
- Dimensions: 27 x 46 x 21 cm.
- Speaker: AD3460X, 5 Ohm.
- Five push buttons for tone adjustment.
- Connections for loudspeaker, tape recorder and gramophone.
- Tubes: ECH81, EF89, EBC81, EL84, EZ80, EM84.
A number of Philips models in the 1950s and '60s were available with the so-called Fishery band, the 60 - 180 meter wave range, usually instead of the FM band. There was also a variant of this device with FM, the B4X82A.
There is now a lot of single sideband modulation worked, in the 80 meter amateur band for example, but that is not to receive with this kind of old radios.
